Does the design require greater forming margin alongside abrasion resistance?
Finished wear parts / GOREX 400—500
Hardness at the core. Evidence in every delivery.
GOREX is our family of finished wear parts and cut-to-requirement wear components for construction, recycling, mining and material handling. Every quoted class is tied to documented source steel, the actual producing mill and order-specific inspection requirements.
GX / 450GB/T 24186-2022NM450E SOURCE FRAMEWORK
01 / Performance spectrum
Three grades. One controlled hardness spectrum.
Compare surface hardness, minimum tensile strength, elongation and specification thickness on one scale before entering the complete product dossier.
Surface hardnessComparable first thickness band
- 01400NM400E370–430HBW / ≤ 80 mm
- Rm minimum
- 1200 MPa
- A50 minimum
- 10%
- Specification limit
- 120 mm
- 02450NM450E420–480HBW / ≤ 80 mm
- Rm minimum
- 1250 MPa
- A50 minimum
- 8%
- Specification limit
- 120 mm
- 03500NM500E470–540HBW / ≤ 70 mm
- Rm minimum
- 1350 MPa
- A50 minimum
- 7%
- Specification limit
- 100 mm
One impact-abrasion study / test-specific
A measured signal—not a wear-life promise
Under the cited HBIS/Tangsteel test conditions, the tested NM500 steel recorded 8.3 times the wear resistance of Q355B. Abrasive, impact, hardness and geometry change the result.
IndicativeNM5008.3×Q355B baseline
Contracted source framework
Open the complete comparisonFramework values apply only when contracted and confirmed for the order. Shipment conformity depends on the original mill EN 10204 3.1 document and GOREX release controls.
Technical proof framework
02 / Class selection
Select by asking the right questions
02450HBW
Indicative
Open grade dossierGOREX 450
How should sliding abrasion, impact and workshop processing be balanced?
03500HBW
Indicative
Open grade dossierGOREX 500
Does higher nominal hardness suit the real geometry, impact and process route?
03 / Field
Five operating fields. No universal grade.
A1
Buckets & attachments
Map sliding abrasion, impact zones and welded geometry.
A2Mining & quarry
Define material flow, fragment size and impact energy.
A3Recycling & demolition
Assess irregular impact, scrap edges and service intervals.
A4Material handling
Locate flow angles, transitions and wear paths.
A5Forestry & agriculture
Balance soil contact, stone impact and repairability.
04 / Core
Centre hardness enters qualification
Surface hardness is only the start. The GOREX qualification plan ties the finished wear part to verified source plate and requires both surface and centre checks, even where the base standard makes centre hardness optional.
SpecifiedThe requirement is specified; the actual measurement belongs to the order inspection document.
0 mmt / 2t mm
SurfaceCentreSurface
HBWSECTION / CENTRELINE
05 / Trace
One unbroken document flow
- 01Heat
- 02Plate
- 03Test
- 04Document
- 05Delivery
06 / Processing
Process from actual order data
Guidance supports decisions — it is not a universal parameter table.
Open technical centre01020304
Welding
Start from actual chemistry, combined thickness, heat input and a qualified WPS.
Cutting
Choose the method by thickness, heat-affected zone and cracking risk.
Bending
Check rolling direction, tooling, radius, surface and exclusion zone.
Machining
Secure machine rigidity, workholding, tooling and trial parameters.
07 / Release
Qualification before release
The first three released shipment lots target true EN 10204 3.2 only when the required independent or authorized validation is actually arranged. Every shipment is assessed against its specified inspection plan.
See the quality gate08 / Supply
Confirmed on request
Inventory and lead time are never assumed. Thickness, dimensions, quantity and inspection scope are confirmed in each quotation.
- 01State the requirement
- 02Verify the supply route
- 03Confirm the quotation
09 / Quote dossier
Build a complete quote dossier
Send the technical conditions that shape material selection, inspection and delivery.
